Cable approved by:


DRSKABEL Specification: NYY XLPE PVC PVC


1x120MM NYY PVC PVC CABLE
Cross Section :1x120mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :18,7(mm)
Weight :1.251(kg/km)

Download Detail


1x150MM NYY PVC PVC CABLE
Cross Section :1x150mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :20,5(mm)
Weight :1.535(kg/km)

Download Detail


1x185MM NYY PVC PVC CABLE
Cross Section :1x185mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :22,6(mm)
Weight :1.906(kg/km)

Download Detail


1x240MM NYY PVC PVC CABLE
Cross Section :1x240mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :25,7(mm)
Weight :2.483(kg/km)

Download Detail



1x300MM NYY PVC PVC CABLE
Cross Section :1x300mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :29,5(mm)
Weight :3.158(kg/km)

Download Detail


1x400MM NYY PVC PVC CABLE
Cross Section :1x400mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :34,1(mm)
Weight :4.007(kg/km)

Download Detail


1x500MM NYY PVC PVC CABLE
Cross Section :1x500mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :37,7(mm)
Weight :5.091(kg/km)

Download Detail


3x1.5MM2 NYY PVC PVC CABLE
Cross Section :3x1.5mm2 NYY (YVV-U)
Voltage :0,6/1kV (1.2kV)
Diameter :10,3(mm)
Weight :171(kg/km)

Download Detail



3x2.5MM2 NYY PVC PVC CABLE
Cross Section :3x2.5mm2 NYY (YVV-U)
Voltage :0.6/1kV (1.2kV)
Diameter :11.1(mm)
Weight :215(kg/km)

Download Detail


3x4MM2 NYY PVC PVC CABLE
Cross Section :3x2,5mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :13.7(mm)
Weight :308(kg/km)

Download Detail


3x6MM2 NYY PVC PVC CABLE
Cross Section :3x6mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :15(mm)
Weight :390(kg/km)

Download Detail


4x1.5-NYY-XLPE-PVC-PVC CABLE
Cross Section :4x1.5mm2 NYY (YVV-U))
Voltage :0,6/1kV (1,2kV)
Diameter :11.1(mm)
Weight :205(kg/km)

Download Detail



4x2,5MM2 NYY PVC PVC CABLE
Cross Section :4x2,5mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :12,2(mm)
Weight :267(kg/km)

Download Detail


4x4MM2 NYY PVC PVC CABLE
Cross Section :4x4mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :14,9(mm)
Weight :402(kg/km)

Download Detail


4x6MM2 NYY PVC PVC CABLE
Cross Section :4x6mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :16,3(mm)
Weight :509(kg/km)

Download Detail


4x10MM2 NYY PVC PVC CABLE
Cross Section :4x10mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :18,5(mm)
Weight :691(kg/km)

Download Detail



4x16MM2 NYY PVC PVC CABLE
Cross Section :4x16mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :21,3(mm)
Weight :991(kg/km)

Download Detail


4x25MM2 NYY PVC PVC CABLE
Cross Section :4x25mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :24,8(mm)
Weight :1.450(kg/km)

Download Detail


4x35MM2 NYY PVC PVC CABLE
Cross Section :4x35mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :27,7(mm)
Weight :1.906(kg/km)

Download Detail


4x50MM2 NYY PVC PVC CABLE
Cross Section :4x50mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :31,2(mm)
Weight :2.624(kg/km)

Download Detail



4x70MM2 NYY PVC PVC CABLE
Cross Section :4x70mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :35,7(mm)
Weight :3.611(kg/km)

Download Detail


4x95MM2 NYY PVC PVC CABLE
Cross Section :4x95mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :41,7(mm)
Weight :4.916(kg/km)

Download Detail


4x120MM2 NYY PVC PVC CABLE
Cross Section :4x120mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :45,8(mm)
Weight :6.126(kg/km)

Download Detail


4x150MM2 NYY PVC PVC CABLE
Cross Section :4x150mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :50.1(mm)
Weight :7.519(kg/km)

Download Detail



4x185MM2 NYY PVC PVC CABLE
Cross Section :4x185mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :55,3(mm)
Weight :9.267(kg/km)

Download Detail


4x240MM2 NYY PVC PVC CABLE
Cross Section :4x240mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :62.9(mm)
Weight :4.12.073(kg/km)

Download Detail


5x1.5MM2 NYY PVC PVC CABLE
Cross Section :5x1.5mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :12.1(mm)
Weight :247(kg/km)

Download Detail


5x2.5MM2 NYY PVC PVC CABLE
Cross Section :5x2.5mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :13.2(mm)
Weight :317(kg/km)

Download Detail



5x4MM2 NYY PVC PVC CABLE
Cross Section :5x4mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :16,2(mm)
Weight :486(kg/km)

Download Detail


5x6MM2 NYY PVC PVC CABLE
Cross Section :5x6mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :18(mm)
Weight :546(kg/km)

Download Detail


5x6MM2 NYY PVC PVC CABLE
Cross Section :5x6mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :20.1(mm)
Weight :887(kg/km)

Download Detail


5x16MM2 NYY PVC PVC CABLE
Cross Section :5x16mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :22,8(mm)
Weight :887(kg/km)

Download Detail



5x25MM2 NYY PVC PVC CABLE
Cross Section :5x25mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :26.5(mm)
Weight :1.820(kg/km)

Download Detail


5x35MM2 NYY PVC PVC CABLE
Cross Section :5x35mm2 NYY (YVV-U)
Voltage :0,6/1kV (1,2kV)
Diameter :29.9(mm)
Weight :2.410(kg/km)

Download Detail


1x95MM2 NYY PVC PVC CABLE
Cross Section :1x95mm2 NYY (YVV-R)
Voltage :0,6/1kV (1,2kV)
Diameter :17(mm)
Weight :1.012(kg/km)

Download Detail
